冷再生工作装置主要由大臂、转子、转子罩等组成。拌刀为子弹头式，罩壳为全浮动拖式。冷再生机租赁厂家提醒您，工作装置是稳定土再生机的主要工作机构，直接体现该机功能。作业过程中，作业的平整度、压实度、拌料的含水量等因素直接影响到再生效果及生产效率。

The cold regeneration working device is mainly composed of boom, rotor, rotor cover, etc. The mixing knife is bullet head type, and the cover is full floating towed type. The leasing manufacturer of the cold regenerator reminds you that the working device is the main working mechanism for stabilizing the soil and reinvigorating it, which directly reflects the function of the machine. During the operation, the flatness, compactness and moisture content of the mixture directly affect the regeneration effect and production efficiency.

举升臂

Boom

左右举升臂和两根横梁组成，与主机架的后部支座铰接，它可绕这个铰接轴转动，由举升臂升降油缸来驱动。其主要作用是带动整个工作装置随车运动和升降运动。举升臂外侧防护板可以取下，里面有工作马达和胶管。

The left and right boom is composed of two beams, which are hinged with the rear support of the main frame. It can rotate around this hinge axis and is driven by the boom lifting cylinder. Its main function is to drive the whole working device to move with the vehicle and move up and down. The outer guard plate of the boom can be removed, and there are working motors and rubber hoses inside.

工作转子

Working rotor

转子是由刀库、刀头、刀座等组成。转子通过内外齿圈、压盘、和举升臂连接在一起。内齿圈与举升臂固定在一起，外齿圈与支座定在一起，的旋转部件与转子固定在一起，内外齿圈啮合用压盘从转子两端压合。

The rotor is composed of tool magazine, tool head, tool holder, etc. The rotor is connected with the lifting arm through the inner and outer gear rings, pressure plates and. The inner gear ring is fixed with the lifting arm, the outer gear ring is fixed with the support, the rotating parts of the are fixed with the rotor, and the inner and outer gear ring mesh is pressed from both ends of the rotor with a pressure plate.

动力来自工作马达，其作用是减小转速，增加扭矩，并把动力传递给转子。转子的作用是铣削、破碎、拌合物料，并把物料抛到后面。转子的铣刨深度可从举升臂油缸上的标尺读出来。

The power comes from the working motor, whose function is to reduce the speed, increase the torque and transfer the power to the rotor. The role of the rotor is to mill, break, mix materials and throw them behind. The milling depth of the rotor can be read from the scale on the boom cylinder.

转子罩壳

Rotor housing

它由顶罩板和两侧罩板焊接而成的半圆形罩壳。其后部有后尾门，开度由油缸控制，作用是刮平拌合好的物料，前部有前尾门，开度由两拉杆调整，作用是控制物料粒度，开度越小粒度越小，但作业阻力也越大。整个转子罩空套在内齿圈上，进行铣拌作业时，罩壳浮在地面上，与地面形成一个封闭的空间。

It is a semi-circular shell welded by the top cover plate and the cover plates on both sides. There is a rear tailgate at the rear, whose opening is controlled by the oil cylinder, which is used to scrape and level the mixed materials. There is a front tailgate at the front, whose opening is adjusted by two pull rods, which is used to control the particle size of materials. The smaller the opening, the smaller the particle size, but the greater the operating resistance. The whole rotor casing is sleeved on the inner gear ring. When milling and mixing, the casing floats on the ground, forming a closed space with the ground.

这样铣拌刀具切削混凝土，并以一定的速度抛进来，撞击转子罩的内面，使稳定土进一步破碎，同时把各种成分混合均匀，以一定的速度把物料从转子上面的空间抛到后面，后物料从后尾门流出，后尾门将其刮平。

In this way, the milling cutter cuts the concrete and throws it in at a certain speed, hitting the inner surface of the rotor cover, further crushing the stabilized soil, and mixing the various components evenly. At a certain speed, the material is thrown from the space above the rotor to the rear, and the rear material flows out from the rear tailgate, and the rear tailgate scrapes it flat.

冷再生机工作装置的功能是把旧路面连同基层铣刨下来，在转子罩和转子形成的拌合室内，把铣刨下来的物料和添加得物料破碎并拌合均匀，再以均匀得速度铺在铣刨过得路面上，形成新的稳定土层。您对此有怎样的疑惑或者需求，随时来我们网站http://www.tclqgc.com进行咨询！

The function of the working device of the cold regenerator is to mill the old road surface together with the base layer, break and mix the milled and added materials in the mixing room formed by the rotor cover and rotor, and then pave the milled road surface at a uniform speed to form a new stable soil layer. If you have any doubts or needs about this, please come to our website at any time http://www.tclqgc.com Consult!
